A Smart Way to Move the Camera

Proaim Quad Plus Film Camera Doorway Dolly

Strongest Platform Dolly

The Quad Plus Dolly has an extremely solid Platform constructed from Steel. This makes it extremely robust and can easily handle payloads of up to 200kg/440lb.

Proaim Quad Plus Film Camera Doorway Dolly

Low For The Best Perspective

The platform height of the Dolly is mere 14.5 cm / 5.7" from the ground. We wanted to make it as low as possible to help you capture those low shots very easily.

Proaim Quad Plus Film Camera Doorway Dolly

Personalize It

Quad Plus Dolly can be equipped with Skateboard Wheels for tracks or Rubber Wheels for standard floor use. You can use a tripod, a bazooka, a slider, or any other standard Euro Mount Accessory and configure it to your needs.

See how the Quad Plus Film Camera Dolly Works

01.

Manoeuvres On Small Sets Like No Other Platform Dolly

We designed the Quad Plus Doorway Dolly while keeping mobility and easy operation in mind. With a 2-Wheel steering system, the Proaim Quad Plus Dolly allows for greater turning flexibility. It's capable of negotiating a too tight circle of 2 m (6 ft).
Steering Push bar allows pushing/pulling the Dolly extremely smooth and easy.
Also, The Rear Axle telescopes outward for a wider stance & stability.

Proaim Quad Plus Film Camera Doorway Dolly
Proaim Quad Plus Film Camera Doorway Dolly

02.

Create the Shot you Envision

The Quad Plus Dolly can be configured for use with multiple setups such as slider, jibs, tripods, and geared heads, enabling you to bring the director's vision to reality.
We offer multiple accessories at highly affordable prices so that you can calibrate the Dolly exactly to your needs.

03.

Ultra Versatile Bazooka

The Proaim Telescopic Bazooka with Quick Lock Lever (Euro/ Elemac Mount), when attached to any camera dolly, provides a myriad of camera mount configurations using optional accessories.
Extendable from 69-107 cm / 27-42 inches it enables instant adjustment of the camera position with ease and comfort.
4 Safety Locking Hooks offer extra security to Bazooka camera setups.

Proaim Quad Plus Film Camera Doorway Dolly

Dolly Specifications

Construction

  Dolly Base (Bottom) - Steel
  Dolly Base (Top) -
High-Grade CNC Aluminum

Load Capacity

  up to 200kg/440lb

Dolly Platform LxW

  40 x 23 inch

Wheel Size

  Diameter- 10", Thickness - 1.77", Hard Plastic Rim- 5.5"

Wheel Material

  Hard Rubber

Height from Ground

  14.5 cm

Steering Bar can Tilt Down

  270°

Compatible Track

  Proaim 16ft Heavy-duty Camera Dolly Track, CD-25” (TRK-16-25)
  Proaim Stream 16ft Heavy-duty Cinema Track (TK-STRS-00)

Compatible Track Distance

  22.5" to 27” (Adjustment)

Bazooka Specifications

Construction

  High-Grade CNC Aluminum

Load Capacity

  up to 200 kg / 441 lb

Height

  Maximum: 42” / 107 cm
  Minimum: 27" / 69 cm

Bowl

  100mm

In the Box

Proaim Quad Plus Professional Dolly
Steering Push/Pull Bar
Proaim Telescopic Bazooka with Quick Lock Lever (BZ-286-00)
Proaim Euro/Elemac - Bowl Camera Riser (100mm) (BA-267-00)

Euro Mount Adapter

Construction

  High-Grade CNC Aluminum

Load Capacity

  200 kg / 440 lb

Top Mounting

  Euro / Elemac

Base Mounting

  Plate with 3 holes

Euro Adapter Ø

  80mm / 3.15inch

Euro Plate Ø

  152mm / 5.98inch

Mounting Thread

  M10

Packing Info

Product Weight (Without Packing)

  55.400kg / 122.1lb

Product Volumetric Weight (with packing)

  62.160kg / 137.039lb

User Manual


delivery

Guaranteed Fast Delivery
For all orders

customer service

Quick and Efficient
Customer service

easy returns

Easy Returns
Up to 30 days

warranty

1-Year Warranty
On All Products


Customer Reviews
4.0 Based on 1 Reviews
5 ★
0%
0
4 ★
100%
1
3 ★
0%
0
2 ★
0%
0
1 ★
0%
0
Write a Review

Thank you for submitting a review!

Your input is very much appreciated. Share it with your friends so they can enjoy it too!

Filter Reviews:
D
04/22/2023
David

Can improve but overall a usable dolly if you have a tight budget

Our come with a locking screw misaligned, we had to repair it at our local workshop , shipping back to india will be more expensive, the QC should be better. Proaim however gabe us a further discount. The bazooka is s bit shaky from just a few screws holding it down, you need a ratchet tie to hold it down. When we wanted to buy accessories for this dolly like a side wing plates to add more space on the dolly but , we were told that they don’t make them for this dolly. So we had to custom made ours. The single handle is ok to maneuver the dolly around, but sometimes you need a dual handle like the one on the Super Film Camera Dolly model when pushing and pulling the dolly on tracks with the skater wheels. And like the side wings, they also don’t make abd sell then fir this dolly too. Strange that when they manufactured this door way dolly, they actually build the ability to have the dual handle and side wings attached to it by have the holes already at the bottom and at the end on both side . But yet they don’t take the extra step to manufacture the accessories to support this dolly.
